Key Benefits for lighting Designers

Bright RGB LED Output ∙ Even light distribution ∙ Full, crisp color palette ∙ Clean white range of 3000K-8000K with high CRI ∙ Instant color bumps ∙ Sharp image projections ∙ 9° to 32° zoom ∙ 2 rotating gobo wheels – gobo animation wheel ∙ Super fast iris ∙ Rotating prism ∙ Smooth 100% dimming ∙ 16 bit movement ∙ Variable speed strobe ∙ Baseless design ∙ Near silent when running ∙ Weighs just 48.5 lbs. (22kg).

Key Benefits for Owners

Significantly lower handling and service costs ∙ No starters ∙ No expensive ballast ∙ No cost for discharge lamps ∙ No fragile dichroic colors ∙ No broken reflectors Tight LED binning for identical fixture performance ∙ RDM feedback with service information ∙ More than 20,000 hours lifetime ∙ Auto ranging power supply with low current draw ∙ On-board diagnostic testing, with USB download ∙From a proven moving head manufacturer

Add to Wishlist
Compare
SKU: GLPSPOTONE Categories: ,

Description

AT A GLANCE

Summary of main features

rgb2 zoom2focus2 iris2 rot-gobo2 prism2 rdm art-net

Light Source

  • 400 Watt RGB LED Chipset
  • Average service life: 20,000 hours

Optical System

  • Full red, green and blue additive colour mixing system
  • Motorized Zoom: 10° – 32°
  • Motorized Focus: 2m – infinity

Electromechanical effects

  • Gobo wheel 1: 7 gobos + open, rotating and indexable, interchangeable
  • Gobo wheel 2: 7 gobos + open, rotating and indexable, interchangeable
  • Effect wheel: Rotating and indexable effect wheel, different designs interchangeable
  • Iris: High-speed iris 100%-4% (aperture time 0.2 sec)
  • Prism: Rotating and indexable interchangeable 3-facet prism
  • Separated LED engine prevents contamination
  • 3 Phase Stepper motors

Electronic effects

  • Dimmer: Electronic dimmer 0-100%
  • Shutter: Electronic high-speed shutter 0-10Hz

Movement

  • 8 or 16 bit resolution selectable
  • 540° Pan / 280° Tilt
  • Position feedback
  • High precision 3 phase stepper motor control

Control

  • USITT DMX 512 protocol
  • DMX & Artnet in/out
  • 24 DMX channel: normal mode
  • 31 DMX channel: high resolution mode
  • Back-lit graphic LCD menu with 2 illuminated buttons
  • Over temperature protection
  • Internal colour presets

Specifications

Power Supply

  • Power consumption: Max. 550VA (Watt)
  • Power Input: Auto sensing 100-240V AC, 50-60 Hz
  • Fuse protection

Connectors

  • DMX Data: XLR 3 pin in/out
  • DMX Data: XLR 5 pin in/out
  • Artnet: Neutrik Ethercon
  • Mains power: Neutrik Powercon

Approvals

  • Designed to US Safety standards UL 1573 and UL 8750
  • Designed to Canadian Safety Standard CAN/CSA C22.2 No. 166

Operating Conditions

  • Maximum ambient temperature: 113°F (45°C)

Mounting Options

  • Omega bracket attachment
  • 2 attachment points for safety wire
  • Upright: tripod (supplied) with brackets for ratchet belt
  • Hanging (vertical): M12 nut with lockable installation position for half coupler or other clamp
  • Hanging (horizontal): adjustable bar for sideways truss installation (optional)
  • Any orientation

Shipping

  • Cardboard Box
  • 2 way tour pack (with omega bracket and omega brackets with handle) in flight case

Housing Colours

  • Black available as standard
  • Other colours available on request

Dimensions

  • Length x Width x Height (head vertical): 18.6″ x 9 x 24,3″ (472 x 229 x 618 mm)

Net weight

  • Weight: 50.7 lbs. (23 kg)
Specifications
User Manual
DMX Chart
CAD Files
Photometrics
