Description
The Logic Drive 2X is designed to feed power and control to remote fixtures using the POE latest standard IEEE 802.3 bt (power over Ethernet) and TCP/IP for control. It has 2 output ports and will support a maximum of 92.5 W/port. The Drive 2X includes one LOGIC Wall Con, which is a single gang wall controller that can recall up to 8 recorded scenes from the Drive 2X. Additional Wall Cons may be added to the system, up to 4 pcs on a single controller to have multiple control locations. The Drive 2X supports DMX, Art-Net, and sACN control protocols, and includes an integrated webserver to configure the date/time settings, which are used in the daily/calendar trigger.
Specifications
CONSTRUCTION & PHYSICAL SPECIFICATIONS
- Dimensions: 10.31 x 18.86 x 1.73 in (479 x 245 x 44 mm)
- Fixture Color: Black
- Housing Material: Stamped steel
- Mounting Options: 1U Rack Mount, wall mount via X-slots on bottom of drive housing
- Weight: 7.6 lb (3.45 kg)
CONTROL SPECIFICATIONS
- Operating Modes: Selectable in connected fixtures
- Data Connections:
- Device Data Input: 1 Ethernet (RJ45) and 1 (5-pin) Phoenix connector
- Device output support: POE++, IEEE 802.3 bt, type 4, up to class 8
- Device Data throughout: 1 Ethernet (RJ45) and 1 (5-pin) Phoenix connector
- Wired remote input: 1 RJ-12 (6-conductor, non-standard termination)
- Wired remote output voltage: 12 VDC
- Fixture Setup: Display, RDM, Art-RDM (Artistic License DMX Workshop)
- Standalone Control: Yes
ELECTRICAL SYSTEM SPECIFICATIONS
- Electronic
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current:
- 260 W, 2.60 A @ 100 V
- 260 W, 2.17 A @ 120 V
- 260 W, 1.25 A @ 208 V
- 260 W, 1.14 A @ 230 V
- 260 W, 1.09 A @ 240 V
- Power Supply: Electronic internal
- Recommended Power Cable: 3 x 14 AWG, Belden 2413F, 2412F
- Required Cable Specifications: Cable type: CAT6/A, shielded, Conductor Diameter: ≥23 AWG (≥0.5733 mm), Conductor Material: Solid Bare Copper Wire (stranded not supported), Cable plug: RJ45, CAT6/A, Shielded, Cable Termination: T568B standard
- Total Max Cable Length: Drive to first fixture: ≤100 m / 328 ft, Drive to last fixture: ≤140 m / 460 ft, First fixture to last fixture: ≤40 m / 131 ft
BATTERY SPECIFICATIONS
- Battery Type: Lithium
- Rechargeable: No
- Battery Power: 3 VDC
THERMAL SPECIFICATIONS
- BTU Hour: 887
- Cooling: Fan-assisted convection
- Maximum Surface Temperature: 158 °F (70° C)
- Minimum Distance To Flammable Surface: 11.8 in (0.3 m)
- Operating Temperature Range: -4 °F to 113 °F (-20 °C to 45 °C)
REGULATORY & VOLUNTARY QUALIFICATION
- Canadian Safety: CSA-C22.2 No. 250.2
- Certification Listings: CE/MET/FCC/RoHS
- Environment Details: All indoor permanent installations. Please refer to the User Manual for more detailed information on installation.
- Environment Locations: Dry
- Installation Orientation: Any/Vertical Only/Horizontal Only
- US Safety: UL 2108, UL 1598A
- Warranty: 36-month manufacturer’s limited warranty (for covered regions only)
ACCESSORIES
- Included: Seetronic Powerkon IP65 power cord, 1 LOGICWALLCON, 1 short rack ear bracket, 1 long rack ear bracket
- Optional: LOGIC Wall Con (additional, up to 3 additional)
- Required: RDM Device, Power Supply, Power and Data Interface, etc.
