The AHD-WLV Advanced Digital Hoist Controller was designed to control up to 24 electrically compatible motors, either separately or simultaneously – controlled via CMCseries Digital Cable Remote Controller. Apart from the AHD-LV controller, AHD-WLV is equipped with a wireless module and remote.



• Controls up to 24 hoists from remote
• Controls up to 384 hoists via AHD link
• 2.4GHz working frequency with dual encryption
• Switches with UP/STAY/DOWN function
• GO and Emergency STOP button
• Dry contacts on outputs
• Hoist types: BGV D8, BGV D8+
• Emergency STOP circuit according to: IEC60204, SIL3
• Power output for WMCseries via PowerCon connector
• 1.5m 5G6/5G10mm2 power cable with CEE32A/5p or CEE63A/5p connector
• Outputs protected by RCD30mA and C10A/C16A per output MCB

Complete system consists of these two devices:
BASE unit

• Wireless receiver
• Function key switch with OFF/LOCAL/WIRELESS control modes
• Charger and storage for the REMOTE unit
• LED indication for GO button, wireless signal presence, charger status

• Wireless transmitter
• Linkable with up to 24 channels on hand
• Light and solid construction made from dural that fits easily to hand
• Integrated antenna inside the body
• Standard Motorola Li-Ion battery
• Battery status indication LED
• Beeper alarm function
• Device status LED
• Metal belt clip

CPA – Configurable Automatic Phase Align Switch
APA – Automatic phase sequence check and align
AVM – Automatic voltage check and hoist protection
GCT – Group channel control via CMG remote
RRST – Remote reset function

Compatible with:
• Chainmaster/Movecat/Liftket/Tourrig
• CM lodestar
• Trabes
• Prolyft
• Verlinde/Stagemaker
Any brand of hoist on the market

The device is equipped with unique APA (Automatic Phase Align) module, which guarantees that the motors are moving in the same direction on any align of input phases. If any line wire is disconnected, the hoist controller stops to ensure safe operation.

Another feature of AHD-WLV is the AVM (Automatic Voltage Metering) module. This module checks main voltage for AC 400V +-20%, star configuration and protects the hoists in case of problem with main voltage.

The unit will NOT go into the safe function if:
• one phase is missing
• there is under-voltage on lines
• there is over-voltage on lines

All electrical components carry their own individual CE and comply with the European Directives. The unit is housed in a robust steel 19″ rack with powder coating and complies with CE according to the Certification of conformity that comes with it.

The AHD-WLV has an additional key switch for the Group-stop function. When active, the MCB trip of any hoist will cause an E-STOP on all connected hoists.
