Description
TourPro presents the V8 IP65 LED Profile, a high-output 800w White Source LED Mover. The V8IP LED Profile is feature rich with CMY Colour control, Variable CTO Colour Correction, Elegant Designer series of Gobos, 2 x prisms, selectable overlapping frosts and beautiful dimming. The fourfold diaphragm framing system allows you to precisely achieve individual shading positions of +/- 45o, with added 60o Module rotation, making this a complete solution for any application.
TECHNICAL SPECIFICATIONS
Specifications
Colour spectrum: Cool White
Colour Temperature: 6600K
Colour Render Index: 72 (Optional 90)
LED type: Single 800w LED
Dispersion: 6o – 53o Zoom
Colour: CMY, Variable CTO, 7 Dichroic Wheel
Gobo: 7 Rotating glass, 8 Static
Effects: 4 Facet circular, 6 Facet Linear Prism
Animation: Rotating Animation
Framing: 4 x Diaphragm +/- 45o + 60o Module rotation
Frost: 1 x Light, 1 x Heavy + Overlap
DMX input/output: 3/5 Pin DMX, RDM
Modes: 36/52 Channels
Dimming Curve: Four
Quick electronic strobe 1 ~ 25 Hz
Display: LCD Display
Operating Voltage: AC 100V – 240V 50/60 Hz
Power Consumption: 1180W
Power Connector: True 1 In/out
Housing Material: Die Cast Metal, ABS Plastic
Cooling: Pipe cooling with temp controlled fans
Width: 503mm
Height: 818mm
Depth: 360mm
Weight: 49kg
IP: 65
