Description
Specifications
Light Source
Type
Full Colour RGBW LEDs
Light Source Count
24
Light Source Lifetime
50,000 h
Lumen Output
8864
Colour Generation
• 16 million colors
• Wide palette of pure uniform whites with variable linear colour temperature (2700K – 8000K)
Optical group
• 3 lenses sets available:
10° – SKU 03.LBB015S11FC10
25° – SKU 03.LBB015S11FC25
40° – SKU 03.LBB015S11FC40
• Holographic filters available on request
• Uniform projection on surfaces
Control
• DMX 512 / RDM
• 4-digit 7-segment LED display + 4 soft keys
• Internal operating system updatable via DTS dongle firmware uploader
6 DMX Channel Modes
10 ch(default), 6ch, 6ch (wall) 5ch, 4ch, 1ch
Power consumption: 200W max
Connectors
Signal connection
XLR 5 pins IN/OUT panel connectors
Power Connection
PowerCon In/Out Panel Connectors
Electrical Specifications
Power input
100 – 240 VAC / 50 – 60Hz
Power supply
auto-ranging electronic switch-mode
• Available with IP65 PSU for permanent installations
max. power (@230V)
200 W
Thermal Specifications
Cooling
combined convection and forced air
max. surface temperature (Ta = 45°C)
45 °C / 115 °F
min. ambient temperature (Ta min.)
-10 °C / 40 °F
Mounting Options
Mounting
Dual Bracket for Floor standing and M10 holes for use with clamp
Orientation
any
Location
Indoor permanent
Outdoor Optional
Construction
Housing Color
Black
Housing Material
Aluminum
Protection Rating
IP 20
Construction Features
Optional ACC version – Anti-Corrosion Coating
Dimensions & Weight
Height(Including Yoke)
168.4 mm / 6.63 in
Width (across yoke)
990 mm / 38.98 in
Depth
140.5 mm / 5.53 in
Weight
7.8 kg / 17.2 lbs
