The FL-080 raises a maximum of 203kg up to 8m. high.

Designed for the rough daily business and recommended for challenging set ups. Ensuring maximum convenience, total safety and a lift off load directly from the ground.

The FL-080 is set with a slightly angled body to counter balance loads with perfect stability allowing heavier loads. The FL-830 has an internal ALS emergency system that locks the profiles in place. The easy to handle locking bolts and heavy duty automatic brake winch guarantees safe fold/unfold operations. All Eurotruss lifters are powdercoated black.

Compare
SKU: FL080 Categories: ,

Description

Eurotruss

Technical Specifications

Weight
185 kg / 407.86 lbs
Min. load
25 kg / 55 lbs
Max. load
280Kg (617 lb)
Min. height
1,99 m / 6.53 ft
Max. height
8m (26.2′)
Unfolded base
2.2 x 2.2m (7.2 x 7.2′)
Folded size
60x76x200 cm
Number of profiles
5
Forks
74.5 cm included

Facts

  • Main body made out of 6082-T6 alluminium
  • Steel base and legs DIN 2394, catches and pulleys of ST-37 steel.
  • Winch with automatic brake. Certification CE and GS TÜV.
  • Steel cable guided by channelled steel pulleys with ball bearings.
  • Steel cable DIN 3060. Quality 180 Kg/mm2 twist resistant. Cable diameter : 6 mm.
  • Exclusive ALS system (Auto-Lock Security)

Additional information

Brand

Eurotruss
