P1 Retro Lamp

MEET PERFECTION Portman brings back the retro-style with modern conveniences like on-board dimmers and 7 channels of DMX control. Like a piece of art, the P1 is comfortable in any situation. Perfect for television, theater and live performances. Whether used as a part of the scenery or as a strong light source, the Portman P1 will command attention on any…

SKU: P1RETRO

Description

Beautiful warm tungsten light and smooth dimming in a timeless unique fixture design.

Meet the perfection

Portman P1 is the first retro lamp which is perfect in every detail and beautiful. It can be used as a part of scenery but also as a strong light source.

Overview

– beautiful and high quality
– 7 DMX channels
– built in dimmers and electonic kit
– 7 x 230W halogen lamps
– 3- and 5-PIN XLR connectors
– built in backlight display
– can be easily installed on tripod or hang on clamp

Specifications

Dimensions 85 x 99 x 17 cm (33.5 x 39 x 6.7 in)
Weight 12,5 kg (27,5 lbs)
Rigging 12 mm (1/2 in) hole for spigot or clamp
Mounting position Any
Input voltage 230V 50Hz/60Hz
Power consumption max 1 610W
Power connector Neutrik PowerCon
Control connector Neutrik 3 & 5 PIN XLR (both: in & out)
Light sources 7 x halogen
R7s 118mm OSRAM Haloline PRO 230V
230 W (high efficiency)
Color temperature 1 600 – 2 900K
CRI 100
Optics High reflective hammered reflector
Control features – 7 DMX channels
– RDM
– W-DMX (additional option, can be upgraded any time later)
User interface – High-contrast LCD display
– Highlighted buttons
Other details – silver reflector (standard, can be swapped)
– gold reflector (additional option, can be swapped)
– flight cases (2-,3-,4-row) (additional option)
Warranty 24 months
IP rating IP20
What’s in the box – Fixture
– 2m power cord (PowerCon <-> no plug, naked ends)
– user manual
– 1x spare lamp
Libraries: GrandMA2, ChamSys, ADJ MyDMX, Avolites Titan, Wysiwyg, Vectorworks, Capture, Realizzer… [download here]
  • dimensions
    85 x 99 x 17 cm
  • color temperature
    2900K
  • WEIGHT
    12,5 kg
  • DMX channels
    7
  • input voltage
    230V 50Hz/60Hz
  • power consumption
    max 2100W

Additional information

Brand

Portman

Categories

Lighting

Features

Tungsten-look

Sub-Categories

haloLED™ Lighting

Brand Series

*
