Description
Key Features
- 1 Universe output via direct DMX or Art-Net/sACN
- User Interface Modelled on smartphone icon interfaces for ease of use
- In-Built Wi-Fi for easy connection to the remote app on iOS & Android devices
- Intuitive interface allowing simple control of all fixture attributes
- Dual Network ports allowing seperation of Lighting and Control Data
Hardware Specifications:
- Universes supported: 1
- Direct DMX Outputs 5-Pin XLR: 1
- Master Playback Faders: 2 Chase, 1 Cue Stack, 1 Crossfader
- Multifunction Fixture Faders: 20
- Bump Buttons: Yes
- Attribute Encoders: 0
- Multifunction Encoders: 2 (Colour/Intensity control options)
- Inbuilt 11.6” Multi-touch Display: Yes
- External Monitor: 1920 x 1080 HDMI
- Inbuilt Wi-Fi: Yes
- Network Port: 2
- USB Ports: 2
- Audio Input: 1
- Audio Output: 1
- MIDI Ports in/out: No
- Max Power Consumption (mains): 60w
Software Specifications:
- Max Number of DMX Channels: 512
- Max Number of Fixtures Supported: 512
- Max Number of Cue Stacks: 1
- Max Number of Chases: 2
- Midi & Midi Timecode Supported: No
- OSC Supported: Yes
- RDM Autopatch for fast show patching
- Fixture library of over 60,000 fixture files
- Built in FX generator
- Colour picker and Gel inbuilt Gel library
- Offline designer software available for Windows and Mac
Included Accessories:
- USB Desk light: 1
- Dust cover: 1
- Tablet stand: 1
- 12V power supply: 1
- IEC power cable: 1
Boxed Weights and Dimensions:
- Width: 680 mm (26.8 inches)
- Depth: 420 mm (16.5 inches)
- Height: 230 mm (9 inches)
- Weight: 8kg (17.63 lb)
Flight Cased Weights & Dimensions:
- Width: 650 mm (25.6 inches)
- Depth: 490 mm (19.3 inches)
- Height: 210 mm (8.3 inches)
- Weight (console in flightcase): 16kg (35.27 lb)
Unit Weights and Dimensions:
- Width: 570mm (22.4 inches)
- Depth: 350mm (13.8 inches)
- Height: 106mm (4.2 inches)
- Weight: 5.2kg (11.46 lb)
