VX SERIES 72 WAY SX TOUR RACK

VX SERIES 72 WAY SX TOUR RACK

Distribution of mains power is the backbone of any performance lighting system. Safety, reliability and compliance with the relevant local standards are factors, which ensure that your power distribution system will protect the people who not only use it, but also those who are legally responsible for the overall safety of the installation. The VX…

Description

Distribution of mains power is the backbone of any performance lighting system. Safety, reliability and compliance with the relevant local standards are factors, which ensure that your power distribution system will protect the people who not only use it, but also those who are legally responsible for the overall safety of the installation. The VX Series SX rack is built for Video applications and utilises Industry standard 6 way Socapex outlets for reliable connection to LED Screens and other video devices.

SRS Power distribution devices are internationally recognised for their reliability great value and solid construction.

All power distribution systems are designed, built and tested to comply with EN/IEC and AS/NZS 3439.1:2002 ,3002:2021 ,3000, 3105, 3112 standards.

TECHNICAL SPECIFICATIONS

System Front Features:

  • 72x 16Amp Circuits with individual RCBO—30mA protection
  • 3x 16A Ceeform Auxiliary Circuits with individual RCBO—30mA
  • 3x 10A AU Auxiliary Circuits with individual RCBO—30mA
  • 1x 32A Wilco 3 Phase Auxiliary Output with RCBO and Isolatable RGU Relay.
  • Main Breaker— Front mounted MCCB 4 Pole 400A Breaker
  • PFNP Relay—Phase Missing & Fallen Neutral Protection which is user isolatable if required.
  • RGO Relay—Digital Earth Leakage Relay which is user definable and isolatable.
  • PAC3220 FTP Digital Power meter with FTP monitoring interface.
  • Emergency E Stop.
  • Siemens breakers
  • Front mounted Network ports—Ethercon
  • USB courtesy charging port for User device charging.
  • PFNP Bypass LED Indicator
  • Power OK LED Indicator
  • Mains Input Phase LED Indicators
  • 24RU size

System Front Features:

  • 2x Socapex 6 way outputs (Optional Weilend or Combination)
  • 3x 16A Ceeform Auxiliary Circuits
  • 3x 10A AU Auxiliary Circuits
  • 1x 32A 3 Phase Wilco Auxiliary Output for Chain motor control or additional racks.
  • 400A Powerlock input and thru connectors
  • External secondary earthing point
  • 24RU size
  • Vented casing for unrestricted airflow.
  • Made in Europe

Touring Package Additional Features:

  • Showcase 26RU heavy duty touring Slam Rack with PENN Anti shock suspension frame.
  • 2x SRS Light DSR5.2 RDM dual input DMX Splitters—Front or rear mountable
  • LED Strip Solutions RGB LED Rack Illumination to front and rear.
  • Vented casing for unrestricted airflow.

24, 36 & 48 Way Versions also available.

– All SRS’s products deliver maximum reliability, durability, and the simplicity of control. With its high level of industry experience, SRS develops and manufactures equipment that satisfies customer’s needs while exceeding their expectations.

VX Series— A range of Professional PDU Racks designed with the Video and LED Screen Markets in mind, they have bypass able RCD protection allowing you to be in control of your system like never before. The TX series delivers power where its needed when its needed and how it is needed with no need to compromise safety features to get there.



* All Specifications subject to change without notice
