Description
GeNetix GD4IP is a compact IP65-rated 4-port DMX Splitter that comes with multiple rigging options for easily mounting in your rig. Featuring 1 DMX Input to 4 DMX Outputs and an ‘RDM Disable button’ to strip out RDM data and retime the DMX signal, this ruggedly built device comes with Seetronic IP65 connectors and a PowerCon True1 Mains Input connector.
Overview:
- 4 Port RDM E1.20 Compliant DMX Splitter
- IP65 Rated
- PowerCon True1 Top Mains Input
- M12 Threaded Insert for Clamp Mounting
- Built in Rail for secondary Safety bond when rigged
TECHNICAL SPECIFICATIONS
Hardware Specifications:
- 5 Pin DMX Output Ports: 4
- 5 Pin DMX Input Ports: 1
- RDM Enable/Disable Option: Yes
- Mains Input: PowerCon True1 Top
- IP65 Rated: Yes
- Port Status LEDs: Yes
- M12 Clamp Fixing: Yes
- Safety Bond Fixing Rail: Yes
Software Specifications:
- RDM E1.20 Compliant: Yes
Included Accessories:
- Neutrik powerCON TRUE1 Power Cable: 1
Weights and Dimensions:
- Width: 274mm (10.81 inches)
- Depth: 76mm (3,0 inches)
- Height: 68mm (2.68 inches)
- Weight: 1.40 KG (3.09 lb)
