Description
Key Features
- 6 Universe output via Art-Net/sACN
- 4 RDM Enabled Direct DMX Outputs
- User Interface Modelled on smartphone icon interfaces for ease of use
- In-Built Wi-Fi for easy connection to the remote app on iOS & Android devices
- Intuitive interface allowing simple control of all fixture attributes
- Dual Network ports allowing seperation of Lighting and Control Data
Hardware Specifications:
- Universes supported: 6
- Direct DMX Outputs 5-Pin XLR: 4
- Master Playback Faders: 10
- Multifunction Fixture Faders: 20
- Bump Buttons: Yes
- Attribute Encoders: 4
- Multifunction Encoders: 2 (Colour/Intensity/Position control options)
- Inbuilt 11.6” Multi-touch Display: Yes
- External Monitor: 1920 x 1080 HDMI
- Inbuilt Wi-Fi: Yes
- Network Port: 2
- USB Ports: 2
- Audio Input: 1
- Audio Output: 1
- MIDI Ports in/out: Yes
- Max Power Consumption (mains): 60w
Software Specifications:
- Max Number of DMX Channels: 3072
- Max Number of Fixtures Supported: 3072
- Max Number of Cue Stacks: 2000
- Max Number of Chases: 2000
- Midi & Midi Timecode Supported: Yes
- OSC Supported: Yes
- RDM Autopatch for fast show patching
- Fixture library of over 60,000 fixture files
- Built in FX generator
- Colour picker and Gel inbuilt Gel library
- Offline designer software available for Windows and Mac
Included Accessories:
- USB Desk light: 1
- Dust cover: 1
- Tablet stand: 1
- 12V power supply: 1
- IEC power cable: 1
Boxed Weights and Dimensions:
- Width: 900mm (35.4 inches)
- Depth: 420mm (16.5 inches)
- Height: 230mm (9 inches)
- Weight: 10kg (22.04 lb)
Flight Cased Weights & Dimensions::
- Width: 860mm (33.8 inches)
- Depth: 490mm (19.3 inches)
- Height: 220mm (8.7 inches)
- Weight (console in flightcase): 20kg (44.09 lb)
Unit Weights and Dimensions::
- Width: 760mm (29.9 inches)
- Depth: 350mm (13.8 inches)
- Height: 106mm (4.2 inches)
- Weight: 6.1kg (13.44 lb)
